8 Different Types of Firewalls Explained (with Use Cases)

Enterprise Networking Planet content and product recommendations are editorially independent. We may make money when you click on links to our partners. Learn More.

A firewall is a security measure that monitors and controls incoming and outgoing network traffic based on predetermined security rules. Firewalls act as a barrier between a trusted internal network and untrusted external networks, such as the Internet.

There are several types of firewalls, each with its unique features, advantages, and disadvantages. In this article, we will explore the different types of firewalls and their use cases, and help you determine which is best suited for your specific situation.

Packet-filtering firewalls

Packet-filtering firewalls work on the network layer of the OSI model, examining each incoming and outgoing packet’s header information (such as source and destination IP addresses, port numbers, and protocols) to determine whether the packet should be allowed or blocked based on preconfigured rules.


  • Simplicity: Packet-filtering firewalls are easy to understand and implement.
  • Low resource usage: They have a minimal impact on network performance.
  • Cost-effective: They are typically less expensive than more advanced firewalls.


  • Limited security: These firewalls do not analyze the packet’s content, leaving networks vulnerable to more sophisticated attacks.
  • Susceptible to IP spoofing: Attackers may bypass packet-filtering firewalls by forging IP addresses.

When to use a packet-filtering firewall

Packet-filtering firewalls are suitable for small networks or environments with limited security requirements, such as small businesses or home networks that primarily require basic protection from common threats.

Stateful inspection firewalls

Stateful inspection firewalls operate on the transport layer of the OSI model. They maintain a state table to track the state of each active connection, which allows them to inspect both packet headers and payloads. Stateful inspection firewalls can filter packets based on their context, providing more robust security than packet-filtering firewalls.


  • Improved security: Stateful inspection firewalls provide a more in-depth analysis of network traffic, making them more effective at blocking malicious activity.
  • Lower false positive rates: By tracking the state of each connection, they can better identify legitimate traffic and reduce false positives.


  • Higher resource usage: Stateful inspection firewalls consume more resources than packet-filtering firewalls, which may impact network performance.
  • More complex to configure and manage: Due to their advanced functionality, they require more expertise to configure and maintain.

When to use a stateful inspection firewall

Stateful inspection firewalls are best suited for medium-sized networks or environments with increased security requirements, such as educational institutions, medium-sized businesses, or e-commerce sites.

Application firewalls (proxy firewalls)

Application-layer firewalls, also known as proxy firewalls, operate at the application layer of the OSI model. They act as intermediaries between clients and servers, intercepting and analyzing application-level protocols and data to enforce security policies.


  • Thorough inspection: Application firewalls offer in-depth traffic filtering and inspection.
  • Application-layer security: Protection against application-layer attacks, such as SQL injections and cross-site scripting.
  • Customizability: These firewalls can be customized to block specific content or functions within an application.


  • Performance: They may draw a high performance overhead as they inspect each packet at the application layer.
  • Resource requirements: These firewalls may require additional hardware and software resources.
  • Challenging configuration: They may be more challenging to configure and manage compared to other firewall types.

When to use an application firewall

An application firewall is best suited for organizations that require granular control over application-layer traffic or need to secure web-based applications. For example, if you’re running a high-traffic e-commerce site or managing sensitive customer data, using an application firewall can provide enhanced security and control.

Next-generation firewalls (NGFWs)

Next-generation firewalls (NGFWs) are an evolution of traditional firewalls that offer a more comprehensive and integrated approach to network security. In addition to basic firewall capabilities, NGFWs provide advanced threat protection features like intrusion prevention systems (IPS), deep packet inspection, user and application identification, and sandboxing for threat analysis.


  • Advanced features: Provides advanced security features for better protection.
  • Visibility: Increased visibility and control over network traffic.
  • Advanced threat detection: Ability to identify and block advanced threats like zero-day exploits and advanced persistent threats (APTs).


  • Cost and complexity: Higher costs and complexity compared to traditional firewalls.
  • Resource usage: NGFWs may require more processing power and resources, impacting network performance.

When to use a next-generation firewall

NGFWs are ideal for organizations that need advanced security features to protect against sophisticated threats, monitor user and application-level activities, and ensure compliance with industry regulations. These are suitable for highly regulated industries like finance, healthcare, and even retail, where sensitive data and critical systems are at higher risk.

Cloud-based firewalls

Cloud-based firewalls, also known as Firewall-as-a-Service (FWaaS), are a type of firewall hosted in the cloud and delivered as a subscription-based service. They provide centralized management, configuration, and maintenance of security policies across distributed networks, devices and users.


  • Scalability: Easy deployment and scalability as the network grows.
  • Cost savings: Reduces hardware and maintenance costs.
  • Simpler management: Centralized management and reporting simplify administration.
  • Remote user protection: They can protect dispersed workforces of remote and mobile users, regardless of which network the user is connected to.


  • Dependent on provider: Reliant on the cloud service provider’s availability and performance.
  • Privacy concerns: Possible data privacy concerns due to offsite processing of network traffic.
  • Cost: Subscription costs might be high for some organizations.

When to use a cloud-based firewall

Cloud-based firewalls are ideal for organizations with distributed networks, multiple branches, or remote employees who need a centralized and easily scalable security solution. They are particularly suitable for small and medium-sized businesses that want to avoid the costs and complexity associated with managing on-premises hardware.

Circuit-level gateway firewalls

Circuit-level gateway firewalls operate at the session layer of the OSI model. They establish a connection between the client and the server, acting as a relay for data packets. This type of firewall filters traffic based on the state of the TCP handshake, ensuring that the session is legitimate before allowing data to flow between the two parties.


  • Effectiveness: Fast and efficient filtering of traffic.
  • Efficiency: Lower resource usage compared to application firewalls.
  • Protection against DoS: They can effectively prevent unauthorized access and protect against some denial-of-service (DoS) attacks.


  • Filtering limitations: Limited to filtering at the session layer, meaning they do not inspect deeper-level data.
  • Weak application layer protection: Circuit-level firewalls may not provide sufficient protection against application-layer attacks.

When to use a circuit-level gateway firewall

Circuit-level gateway firewalls are best suited for situations where high-speed traffic filtering is a priority and protection against application-layer attacks is not the primary concern. For example, they can be useful in scenarios where multiple connections need to be quickly and efficiently managed, such as managing traffic for a large enterprise network or a busy website.

Network firewalls

Network firewalls are hardware or software-based solutions that provide security at the perimeter of a network. They act as a barrier between an organization’s internal network and the outside world, filtering and inspecting data packets based on predefined rules.


  • Secure perimeter: These firewalls provide security at the network’s edge.
  • Easy deployment and management: Network firewalls are easy to centrally deploy and manage.
  • Multiple devices: Unlike host-based firewalls, network firewalls protect multiple devices within the network.
  • Performance: They offer high performance for large networks.


  • Lack of application layer visibility: Network firewalls suffer limited visibility into the application layer.
  • Insider threats: They may not be effective against insider threats.
  • Ineffective protection of individual devices: These firewalls may not protect individual devices as effectively as host-based firewalls.

When to use a network firewall

Use network firewalls when you need to protect an entire network from external threats, such as a corporate network or a home network with multiple devices. It is particularly useful for businesses that require strong perimeter security and have a high volume of network traffic.

Host-based firewalls

Host-based firewalls are software applications installed on individual devices, such as laptops, desktops, or servers. They filter incoming and outgoing traffic on a per-device basis and can be configured with specific rules for each device, providing a more granular level of control.


  • Device-level protection: Host-based firewalls can protect individual devices.
  • Granular control: These firewalls offer granular control over the device’s security.
  • Effective against threats: Host-based firewalls are effective against both external and internal threats.
  • Protection beyond the network perimeter: They can protect devices even when they are outside the network perimeter.


  • Complexity: They can be more complex to manage and maintain at scale.
  • Resource usage: These firewalls may impact system performance.
  • Small perimeter: Host-based firewalls are not very effective against network-level attacks.

When to use a host-based firewall

Host-based firewalls are best suited for individual devices, particularly when they are used outside the network perimeter, such as laptops or remote servers. They are also a good choice for organizations that require a high level of control over the security of individual devices and protection against insider threats.

Bottom line: Choosing a firewall for your organization

There is no one-size-fits-all solution when it comes to firewalls. The type of firewall you choose will depend on your organization’s specific needs, its network complexity, and the types of threats you want to guard against.

By understanding the different types of firewalls, their advantages and disadvantages, and their use cases, you can make an informed decision on which firewall is best suited for your needs.

Once you know what type of firewall, you’ll need to develop a strong firewall policy for your organization. Here’s how to design your firewall policy—along with a free template to help you get started.
